Legalett Products - Complimentary Systems and Accessory Products

Complimentary Systems

Find links to helpful information, resources, downloads and technical data for specifying and/or troubleshooting non-Legalett Heating & Ventilation equipment and accessory products including Boiler Interfaces, Floor Finishes and more...

Floor finishes and accessory products with Legalett Air-Heated Radiant Floors & Shallow Slab Foundation SystemsIn the Complimentary Products section we cover the following subjects:



Water Quality Guidelines



There are two basic types of hot water systems, each with differing recommendations.



1. Closed Systems

A closed system is a water system that circulates the same (non-potable) water through a loop from the water heating source to the Legalett heating insert. This requires a dedicated heat source, OR a heat source with a heat exchanger to transfer energy between potable water and the non-potable water used with the Legalett heaters. The heat source may be a hot water tank with an internal or external add-on heat exchanger, or a boiler.



2. Open Systems

An open system is a water system that circulates potable (domestic) water through the loop from the water heating source to the Legalett heating insert. The same hot water tank as that which is used for domestic (potable) use is also used for the Legalett system.



Read the complete Water Quality Guidelines Data Sheet here. Water Quality Guidelines



Schematics - Water Coil Install



When sizing domestic or combination water heaters for use with Legalett, do NOT add the heating load to the domestic water load. The sizing required for domestic water heating will generally be more than adequate to heat when there is no domestic water demand...



Download the Water Coil Install Schematics here.Water Coil Schematics



Schematics - Boiler / Heat Pump Water Supply



Download the Boiler / Heat Pump Water Supply Schematics here. Boiler Schematics



Dedicated Boiler Interface for Water Coil Units (Optional)



Interlock is not required for most hot water systems that include domestic water supply and use the Legalett specified pump controlled by a Summer/Winter switch. (Refer to the Hot Water Supply Schematic and Heater Control Specifications on the design drawing.)



However, in some scenarios, such as dedicated heat-only boiler hot water system, it may not be desirable or possible to have a boiler armed for the duration of the heating season, i.e. during times when all zones are off. Thus a signal is required from the Legalett units that will arm the boiler and/or turn on a circulation ump. The following are generic wiring diagrams to assist the mechanical contractor in interfacing the Legalett System with a boiler and/or pump, if required...



Read the full Dedicated Boiler Interface for Water Coil Units Data Sheet here.  Boiler Interface Data Sheet



Ventilation and Building Techniques



Since the Legalett System moves air within the slab, and not within the structure, it cannot be used for ventilation. This lack of air movement has many pleasant side effects discussed elsewhere in this site. However, some ventilation air is still required, and this is implemented by using a code-required ventilation system.



Separation of the floor heating system from the ventilation system has another often-overlooked benefit - it reduces the size and required operation time of the ventilation system to only what is required to maintain fresh air...



Click here for more information on Ventilation & Building Techniques for Legalett Systems  Ventilation Techniques



Air Conditioning and Legalett



Cooling and heating are two very opposite processes. Everyone knows that hot air rises, and cold air falls. What does this tell us? Well, it tells us that heating should come from the floor, and cooling should come from the ceiling. Putting your heating and cooling together in either the floor or the ceiling is counterproductive, and reduces the efficiency of the heating or cooling effect...



Click here for more information on Air Conditioning and the Legalett Building System  Air Conditioning



HRV / ERV Operation with Legalett



In a radiant heated building ventilation must be done separately, but remember - in general, the less air movement in a room or the lower the air velocity, the higher the thermal comfort level. The introduction of outside air to the living space for new “well constructed” homes is, however, recommended or required by code to reduce indoor humidity levels and pollutants. The use of a Heat Recovery Ventilator (HRV) or Energy Recovery Ventilator (ERV) is common for this purpose...



Read more here on HRV / ERV Operation with the Legalett Building System  HRV / ERV Operation



Floor Finishes



When choosing floor finishes with any heated floors, it is best to choose floor coverings with low R-values, such

as tile or linoleum. These types of floor coverings allow the most effective delivery of heat into the living space, while maintaining the lowest possible slab temperature, reducing slab heat losses and increasing operating efficiency. These coverings also allow the slab's maximum heating potential to be reached, something that will

not occur with an insulative floor covering.



Download the Construction Heaters and Floor Finishes Data Sheet here.  Floor Finishes Data Sheet
